PH1800 Series (8-10KW)

High Frequency Hybrid Solar Inverter

This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.

Features:

• Pure sine wave inverter
• Programmable multiple operation modes: Grid-tie, off-grid and grid-tie with backup
• Configurable input voltage range for home appliances and personal computers via LCD setting
• Configurable battery charging current based on applications via LCD setting
• Configurable AC/Solar Charger priority via LCD setting
• Compatible to mains voltage or generator power
• Auto restart while AC is recovering
• Overload/ Over temperature/ short circuit protection
• Smart battery charger design for optimized battery performance
• Cold start function
• Wifi remote monitoring (optional)

Specification:

MODEL PH18-8048 PH18-10048
Nominal Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 8000W 10000W
Surge Power 16000W 20000W
Waveform Pure Sine Wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%
Output Frequency 60Hz or 50Hz
Inverter Efficiency(Peak) 93%
Transfer Time 10ms (UPS) 20ms (APL)
AC INPUT
Nominal Input Voltage 230VAC
Max AC Input Voltage 300VAC
Selectable Voltage Range 170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105)
Frequency Range 50Hz / 60Hz(Auto detection)
BATTERY
Normal Voltage 48VDC
SOLAR CHARGER & AC CHARGER
AC Charging Current 2-120A
Maximum PV Array Open Circuit Voltage 145VDC
PV Array Open Circuit Voltage 60-130VDC
Cold Start Voltage 46VDC
Solar Charging Current 160A
Default Charging Current 160A
Maximum Charge Current 280A
Charging Algorithm 3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI)
MECHANICAL SPECIFICATIONS
Machine Dimensions(W*H*D)(mm) 503*600*141.2
Net Weight(kg) 21.0
OTHER
Safety Certification CE
Operating Temperature 0°C~50°C
Storage Temperature -15°C ~60°C
