Key Benefits:
- High-Efficient Energy Storage Batteries.
- Modular design providing escort in emergency.
- The safest lithium solar battery material (LFP) battery
- Integrated battery management system (BMS)
- Battery system designed for PV household application
- Longer cycle life 6000 Cycles (25℃, 80% DOD)
Specification:
MODEL | LP20-48200 | LP20-48250 | |
---|---|---|---|
Nominal Voltage | 51.2V | ||
Nominal Capacity | 200Ah | 250Ah | |
Nominal energy | 10240Wh | 12800Wh | |
Life Cycles | 6000 Cycles (25℃, 80% DOD) | ||
Recommended Charge Voltage | 57.6V | ||
Recommended Charge Current | 40A | 50A | |
End Of Discharge Voltage | 44V | ||
Standard Method | Charge | 40A | 50A |
Discharge | 100A | 125A | |
Maximum Continuous Current | Charge | 150A | 150A |
Discharge | 150A | 150A | |
BMS Cut-Off Voltage | Charge | 58.4 V (3.65V/Cell) | |
Discharge | 44.0V (2s) (2.75V/Cell) | ||
Temperature | Charge | -4 ~ 113 ℉ (0 ~ 45℃ ) | |
Discharge | -4 ~ 131 ℉ (-20 ~ 55 ℃ ) | ||
Storage Temperature | 23~95 ℉ (-5~35℃ ) | ||
Shipment voltage | ≥51.2V | ||
Module Parallel | Up to 15 units | ||
Communication | CAN2.0/RS232/RS485 | ||
Case Material | SPPC | ||
Dimension (L x W x H) | 540 x 500 x 665 mm 21.3 x 19.7 x 26.2” |
||
Approx. Weight | 242lbs (110 kg) | 264lbs (120 kg) | |
Charge Retention And Capacity Recovery Capability | Standard charge the battery, and then put aside at room temperature for 28d or 55 ℃ for 7d, Charge retention rate≥90%, Recovery rate of charge≥90 |
