Features:
• Pure sine wave output
• 3 Steps charging
• MFD (multi-function display)
• Overload and short-circuit protection
• Set charging voltage/charging current.
• Battery low voltage shutdown point can be set to 10/10.5/11/11.5V
• Power-save mode
• Set utility priority/ Battery priority
• Set utility input wide/narrow range
• Inverter voltage can be set to 220V:220V/230V/240V
• Inverter frequency can be set to 50/60Hz
• Set utility charging on/off switch
• Acid or Lituium select
• WiFi port (optional)
Specification:
| MODEL | EP30-4KW PLUS | EP30-5KW PLUS | EP30-6KW PLUS | |
|---|---|---|---|---|
| Nominal Battery System Voltage | 24VDC | 48VDC | 48VDC | 48VDC |
| INVERTER OUTPUT | ||||
| Rated Power | 4KW | 5KW | 6KW | |
| Surge Rating | 12000VA | 15000VA | 18000VA | |
| Capable Of Starting Electric Motor | 2HP | 3HP | ||
| Waveform | Pure sine wave / same as input (bypass mode) | |||
| Nominal Output Voltage RMS | 220V / 230V / 240VAC ±10% (RMS) | |||
| Output Frequency | 50Hz / 60Hz ±0.3Hz | |||
| Inverter Efficiency (Peak) | >88% | |||
| Line Mode Efficiency | >95% | |||
| Power Factor | 1.0 | |||
| Typical Transfer Time | 10ms(max) | |||
| AC INPUT | ||||
| Voltage | 230VAC | |||
| Selectable Voltage Range | 96~132VAC 155~280VAC(For personal computers) | |||
| Frequency Range | 50Hz / 60Hz(Auto sensing) 40~80Hz | |||
| BATTERY | ||||
| Minimum Start Voltage | (10V / 10.5V / 11V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Low Battery Alarm | (10V / 10.5V / 11V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Low Battery Cut Off | 10V / 10.5V / 11V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| High Voltage Alarm | (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| High Battery Voltage Recover | (13.8-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC) | |||
| Idie Consumption-Search Mode | Load ≤100±20W(220V) | |||
| CHARGER | ||||
| Output Voltage | Depends on battery type | |||
| Charge AC Input Breaker Rating (230V) | 4-6K/40A | |||
| Overcharge Protection S.D. | 15.7VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode) | |||
| Maximum Charge Current | 60A | 30A | 35A | 40A |
| BYPASS & PROTECTION | ||||
| Input Voltage Waveform | Sine wave (grid or generator) | |||
| Nominal Input Frequency | 50Hz or 60Hz | |||
| Overload Protection (SMPS Load) | Circuit breaker | |||
| Output Short Circuit Protection | Circuit breaker | |||
| AC Input Breaker | 4-6K/50A | |||
| MECHANICAL SPECIFICATIONS | ||||
| Mounting | Wall Mount | |||
| Dimensions (W*H*D) (mm) | 305.4*531*200.3 | |||
| Net Weight (Solar CHG)(kg) | 38.2 | 35.8 | 45 | 45 |
| Shipping Dimensions (W*H*D) (mm) | 400*319*686 | |||
| Shipping Weight (Solar CHG)(kg) | 42.3 | 40 | 49.3 | 49.3 |
| OTHER | ||||
| Operation Temperature Range | 0℃ to 40℃ | |||
| Storage Temperature | -15℃ to 60℃ | |||
| Audible Noise | 60dB MAX | |||
| Display | LED+LCD | |||
